3DMakerPro Smart Grip für Seal 3D Scanner

Product Name ​ ​​​Revopoint MIRACO

Technology ​ ​ ​ ​​Quad-camera Infrared Structured Light

Single-frame Accuracy, up to ​ ​0.05 mm

Fused Point Distance ​ ​ ​0.05 mm

Single Capture Area
at Nearest Distance ​ ​ ​ ​28 x 53 mm at 100 mm

Single Capture Area
at Furthest Distance ​ ​ ​975 x 775 mm at 1000 mm

Two Capture Modes ​ ​ ​ ​Single-shot Mode ,
​ ​ ​ ​ ​ ​ ​Continuous Capture Mode

Scanning Speed，up to ​ ​ ​15 fps

Minimum Scan Volume ​ ​ ​10 x 10 x 10 mm

Maxmium Scan Volume ​ ​ ​4000 x 4000 x 4000 mm

Working Distance ​ ​ ​ ​100 ~ 1000 mm

Screen ​ ​ ​ ​ ​ ​6” 2k AMOLED Touch Screen

Auxiliary Lighting ​ ​ ​ ​Infrared Fill Lights, Flash LEDs

3D Light Source ​ ​ ​ ​Class 1 Infrared Light

Internal Storage ​ ​ ​ ​256 GB eMMC

Position Sensors ​ ​ ​ ​9-axis IMU

Memory (RAM) ​ ​ ​ ​16 GB(Standard) or 32 GB(Pro) DDR4

RGB Camera Resolution, up to ​ ​48 Megapixels

Scanner Weight ​ ​ ​ ​750 g

Dimensions（L x W x H） ​ ​ ​200 x 50 x 110 mm

Battery Capacity. ​ ​ ​ ​Internal lithium Battery 5,000
​ ​ ​ ​ ​ ​ ​mAh, supporting up to 2-hour
​ ​ ​ ​ ​ ​ ​continuous scanning

CPU ​ ​ ​ ​ ​ ​8-core CPU，2.4 GHz

Tracking Methods ​ ​ ​ ​Feature , Marker

Protection Rating ​ ​ ​ ​IP45

Connector Type ​ ​ ​ ​USB Type-C

Wi-Fi Type ​ ​ ​ ​ ​Wi-Fi 6

Compatible Operating Systems ​ ​Windows 10/11 (64-bit), macOS

Native system ​ ​ ​ ​Native Android System

Special Object Scanning ​ ​ ​Use scanning spray for
​ ​ ​ ​ ​ ​ ​transparent, dark, or
​ ​ ​ ​ ​ ​ ​highly reflective objects.

Scanning Environment ​ ​ ​Indoors and Outdoors

Output Formats ​ ​ ​ ​PLY, OBJ, and STL

3D Printing Compatible ​ ​ ​Yes
